919-136P-71AX by amphenol rf
Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

919-136P-71AX

RF Connector MCX Right Angle Crimp Plug for RG-179 75 Ohm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 919-136P-71AX is a 75O MCX angle plug connector designed for broadband RF applications. It features snap-on coupling per CECC 22220 with gold-plated brass male contacts and beryllium copper female contacts, providing reliable electrical performance across DC to 6 GHz frequency range. The connector exhibits a maximum VSWR of 1.1 at DC–2.5 GHz for right-angle configuration, insertion loss of 0.10 dB at 1 GHz, and RF leakage of 60 dB minimum for flexible cable and 70 dB minimum for semi-rigid cable at 1 GHz. It operates over a temperature range of -55°C to +155°C with a voltage rating of =335 Vrms and dielectric withstand voltage of 1,000 Vrms. The connector uses hex crimp termination for the braid/jacket and solder termination for the center conductor, making it suitable for automotive, wireless LAN, broadband, and wireless infrastructure applications where compact size and reliable RF performance are essential.

Search Keywords: 919136P71AX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
919-136P-71AX
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bag
Type:
MCX
Impedance:
75 Ohm
Operating Frequency:
0 to 6 Hz to GHz
Gender:
Plug
Mounting:
Cable Mount
Body Orientation:
Right Angle
Terminate To:
RG179/U Cable
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
8.6 x 10 mm

FREQUENTLY ASKED QUESTIONS

Is 919-136P-71AX RoHS compliant?

Yes, 919-136P-71AX is RoHS compliant.

What is the lead time for 919-136P-71AX?

The standard lead time for 919-136P-71AX is approximately 14 days. In-stock quantities ship from Master Electronics.

IN STOCK: 243

Ships today, if you order in

Minimum Order Quantity: 2

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
2
$23.07
10
$13.92
25
$11.57
51 +
$10.38
