901-9511-1 by amphenol rf
Image is representational - see mfr. specs

901-9511-1

Amphenol RF

The 901-9511-1 is a straight SMA plug connector for flexible cables, featuring a stainless steel body with gold plating. ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 901-9511-1 is a 50-ohm straight SMA plug designed for termination with flexible cables from Cable Group C1 (RG-55, 142, 223, 400). It features a durable stainless steel body and center contact, both with gold plating for excellent conductivity and corrosion resistance. The connector utilizes a crimp termination for the cable braid and a solder termination for the center contact, ensuring a secure and reliable connection. Built in accordance with MIL-C-39012, this high-performance connector operates from DC to 12.4 GHz and is ideal for instrumentation, telecommunications, and general-purpose cable assembly applications.

Search Keywords: 90195111

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
901-9511-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 12.4 Hz to GHz
Gender:
Plug
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
Flexible Cable
Termination Method:
Crimp
Operating Temperature:
-65 to 165 °C
Dimension:
27.9 x 7.92 x 7.92 mm

IN STOCK: 505

Can Ship immediately

Manufacturer Stock: 1   can ship 5/4/26

Minimum Order Quantity: 5

Factory Lead-Time 13 Weeks can ship 7/22/26

Qty
Unit Price
5
$20.60
10
$17.97
25
$16.79
50
$12.59
100
$10.72
250
$10.60
500 +
$10.49
