142231 by amphenol rf
Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

142231

A bulkhead-mount SMB crimp jack connector designed for use with RG-178B/U and RG-196A/U coaxial cables. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 142231 is an SMB bulkhead crimp jack from Amphenol Connex, engineered for terminating RG-178B/U and RG-196A/U cables. This connector features a gold-plated brass body, contact pin, hex nut, and lock washer, providing excellent durability and signal conductivity. A natural Teflon insulator ensures reliable electrical performance. Designed for panel mounting, it utilizes a 10-32UNF-2A thread and is ideal for creating secure, high-quality RF connections in various electronic systems and equipment.

Search Keywords: 142231

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
142231
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
SMB
Impedance:
50
Operating Frequency:
0 to 4 Hz to GHz
Gender:
Jack
Mounting:
Panel Mount
Body Orientation:
Straight
Terminate To:
Coaxial Cable
Termination Method:
Crimp
Operating Temperature:
-65 to 165 °C
Dimension:
18 mm

FREQUENTLY ASKED QUESTIONS

Is 142231 RoHS compliant?

Yes, 142231 is RoHS compliant.

What is the lead time for 142231?

The standard lead time for 142231 is approximately 14 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 161

Ships today, if you order in

Manufacturer Stock: 1   can ship 10/26/26

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks can ship 1/19/27

Price (USD)

Qty
Unit Price
5
$9.47
25
$6.69
50
$6.67
100
$6.32
250
$5.98
500
$5.74
1,000
$5.54
2,500 +
$5.53
Log in for special pricing
