135101-01-48.00 by amphenol rf
Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

135101-01-48.00

SMA Straight Plug to SMA Straight Plug on RG-316 cable 48 inches ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

135101-01-48.00 is a coaxial cable assembly consisting of two SMA crimp plugs connected via RG-316/U coaxial cable with a total length of 48.00 inches (1.219 meters). The assembly features a nominal impedance of 50 ohms and is designed to operate across a frequency range from DC to 3.0 GHz, with continuity verified per design requirements. The cable is terminated with SMA crimp plugs (P/N 132114) on both ends and includes heat shrink tubing at typical locations for strain relief and protection. This assembly is ideal for RF and microwave applications requiring reliable signal transmission in test equipment, instrumentation, and communication systems where precise impedance matching and low signal loss are essential.

Search Keywords: 135101014800

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
135101-01-48.00
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544200000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG

FREQUENTLY ASKED QUESTIONS

Is 135101-01-48.00 RoHS compliant?

Yes, 135101-01-48.00 is RoHS compliant.

What is the lead time for 135101-01-48.00?

The standard lead time for 135101-01-48.00 is approximately 14 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 0

Manufacturer Stock: 1   can ship 10/26/26

Factory Lead-Time 14 Weeks can ship 1/18/27

Price (USD)

Qty
Unit Price
1
$28.98
5
$27.11
10
$26.30
25
$25.23
50
$22.23
100
$19.71
250 +
$18.83
