031-71014-RFX by amphenol rf
Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

031-71014-RFX

The 031-71014-RFX is a 75 Ohm BNC jack connector designed for crimp termination onto RG-179 and RG-187 coaxial cables. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 031-71014-RFX is a 75 Ohm BNC jack connector designed for crimp termination. It is specifically engineered for compatibility with RG-179 and RG-187 coaxial cables. This connector requires a crimp tool using a .068 inch hex cavity for the contact and a .178 inch hex cavity for the outer ferrule. Proper assembly is achieved with the recommended 227-1221-9 die set and CTL-2 series tool. This Type 2 BNC jack provides a reliable solution for high-frequency 75 Ohm interconnections in applications such as video systems and digital signal routing.

Search Keywords: 03171014RFX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
031-71014-RFX
Alias/AKA:
31-71014-RFX
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
BNC
Impedance:
75 Ohm
Operating Frequency:
N/A
Gender:
Jack
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
RG179 Cable,RG187 Cable
Termination Method:
Crimp
Operating Temperature:
N/A
Dimension:
N/A

FREQUENTLY ASKED QUESTIONS

What replaces 031-71014-RFX?

The recommended replacement for 031-71014-RFX is 112161 from Amphenol RF, available from Master Electronics.

Is 031-71014-RFX RoHS compliant?

Yes, 031-71014-RFX is RoHS compliant.

What is the lead time for 031-71014-RFX?

The standard lead time for 031-71014-RFX is approximately 14 weeks. In-stock quantities ship from Master Electronics.

  Possible Replacement options available.  See Alternatives

IN STOCK: 1,429

Can Ship immediately

Manufacturer Stock: 1   can ship 10/12/26

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks can ship 1/4/27

Price (USD)

Qty
Unit Price
5
$5.06
50
$3.92
100
$2.99
250
$2.85
500
$2.22
1,000
$2.12
2,500
$1.98
5,000 +
$1.96
