031-5329-72RFX by amphenol rf
Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

031-5329-72RFX

This is a commercial grade, 50Ω BNC straight jack connector for printed circuit board applications. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 031-5329-72RFX is a commercial grade, 50Ω BNC straight jack designed for mounting on printed circuit boards. It features a 50Ω nominal impedance and is usable up to 4 GHz with low reflection. The connector utilizes a two-stud bayonet lock coupling mechanism for quick and secure mating, rated for a minimum of 500 mating cycles. As a commercial grade 'RFX' product, it is designed as a low-cost solution, often incorporating die-cast and molded components. This PCB connector is suitable for a wide range of applications, including instrumentation, telecommunications equipment, and computer networking where a reliable RF connection to the board is required.

Search Keywords: 031532972RFX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
031-5329-72RFX
Alias/AKA:
31-5329-72RFX
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Type:
BNC
Impedance:
75 Ohm
Gender:
Jack
Mounting:
Through Hole
Body Orientation:
Straight
Termination Method:
Solder
Dimension:
11 x 16.6 mm

FREQUENTLY ASKED QUESTIONS

Is 031-5329-72RFX RoHS compliant?

Yes, 031-5329-72RFX is RoHS compliant.

What is the lead time for 031-5329-72RFX?

The standard lead time for 031-5329-72RFX is approximately 14 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 1,000

Can Ship immediately

Manufacturer Stock: 1   can ship 11/27/26

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks can ship 2/18/27

Price (USD)

Qty
Unit Price
5
$3.97
50
$3.09
100
$2.72
250
$2.70
500
$2.42
1,000
$2.29
2,500
$2.15
5,000 +
$2.14
Log in for special pricing
