031-5329 by amphenol rf
Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

031-5329

RF Connector BNC Straight PCB Jack Through Hole 50 Ohm ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

031-5329 is a BNC straight printed circuit board jack connector designed for 50O RF applications. It features a nickel-plated brass body with gold-plated beryllium copper contacts and a blunt post (flush) mounting style suitable for PCB integration. The connector is rated for industrial-grade applications and accommodates a 3-leg long post terminal measuring 0.040 inches (1.0 mm) in diameter and 0.125 inches (3.2 mm) long, with a 0.025-inch (0.6 mm) flush depth. BNC connectors are miniature quick-connect/disconnect RF connectors usable up to 11 GHz with low reflection through 4 GHz, making them ideal for cable termination and PCB-mounted RF signal distribution in test equipment, instrumentation, and communication systems.

Search Keywords: 0315329

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
031-5329
Alias/AKA:
31-5329
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
160
Package Type:
TRAY
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
Jack
Mounting:
Through Hole
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
11 x 17 mm

FREQUENTLY ASKED QUESTIONS

Is 031-5329 RoHS compliant?

Yes, 031-5329 is RoHS compliant.

What is the lead time for 031-5329?

The standard lead time for 031-5329 is approximately 14 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 160

Can Ship immediately

Manufacturer Stock: 1   can ship 12/4/26

Minimum Order Quantity: 5

Factory Lead-Time 14 Weeks can ship 2/25/27

Price (USD)

Qty
Unit Price
5
$9.97
25
$8.58
50
$7.77
160
$7.20
320
$7.02
640
$6.69
1,120 +
$6.42
