031-4803-75 by amphenol rf
Image is representational - see manufacturer specifications
Amphenol RF Authorized Distributor

031-4803-75

Conn BNC Adapter 0Hz to 1GHz 75Ohm ST Panel Mount RCP/RCP Gold ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 031-4803-75 is a 75 ohm BNC bulkhead adapter with jack-jack configuration, designed to be isolated from the panel for RF signal transmission. This adapter features a compact design with dimensions of 1.28 inches (32.5 mm) in length and 0.625 inches (15.9 mm) in width, with a panel thickness accommodation of 0.190 inches (4.8 mm). The connector is mounted using a P17 mounting hole pattern and incorporates D12 insulation specifications, ensuring reliable electrical isolation and signal integrity. The adapter is commonly used in RF and microwave systems where panel isolation is required to prevent ground loops and maintain signal quality in sensitive applications.

Search Keywords: 031480375

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
031-4803-75
Alias/AKA:
31-4803-75
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
BNC Adapter
Impedance:
75 Ohm
Operating Frequency:
0 to 1 Hz to GHz
Gender:
RCP/RCP
Mounting:
Panel Mount
Body Orientation:
Straight
Terminate To:
N/A
Termination Method:
N/A
Operating Temperature:
-65 to 165 °C
Dimension:
32.5 x 15.9 mm

FREQUENTLY ASKED QUESTIONS

Is 031-4803-75 RoHS compliant?

Yes, 031-4803-75 is RoHS compliant.

What is the lead time for 031-4803-75?

The standard lead time for 031-4803-75 is approximately 14 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 218

Can Ship immediately

Manufacturer Stock: 128   can ship 10/12/26

Factory Lead-Time 14 Weeks can ship 1/7/27

Price (USD)

Qty
Unit Price
1
$30.36
5
$23.70
10
$20.44
25
$19.30
50
$18.73
100
$18.68
250 +
$15.43
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
