CS-DSDHD26MF0-015 by amphenol cables on demand
Image is representational - see mfr. specs

CS-DSDHD26MF0-015

Amphenol Cables on Demand

A 15-foot, male-to-female cable assembly featuring 26-pin high-density D-Sub connectors with a 1-to-1 pinout. ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The CS-DSDHD26MF0-015 is a 15-foot cable assembly designed for connecting devices with 26-pin high-density D-Sub interfaces. It features a male D-Sub connector on one end and a female D-Sub connector on the other, both with 26 pins in a high-density configuration. The cable is constructed with a grey jacket, 360° copper shielding, and a soldered drain wire for enhanced signal integrity and noise immunity. The connectors are secured with 4-40 UNC threaded thumbscrews on the male side and hex nuts on the female side, ensuring a stable connection with a direct 1-to-1 pinout for all 26 conductors.

Search Keywords: CSDSDHD26MF0015

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Cables on Demand
Part No:
CS-DSDHD26MF0-015
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544422000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bag

IN STOCK: 15

Can Ship immediately

On Order: 50   can ship 6/12/26

Factory Lead-Time 11 Weeks

Qty
Unit Price
1
$42.29
5
$40.18
10
$34.32
25
$32.37
50
$30.82
100
$29.37
250 +
$27.53
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
