AZ973-1A-12DC4 by american zettler
Image is representational - see manufacturer specifications
American Zettler Authorized Distributor

AZ973-1A-12DC4

40AMP Mini-ISO Automotive Relay 12VDC coil SPST-NO

View Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

40AMP Mini-ISO Automotive Relay 12VDC coil SPST-NO

Search Keywords: AZ9731A12DC4

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ973-1A-12DC4
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Contact Form:
SPST-NO (1 Form A)
Relay Construction:
Non-Latching
Max Contact Current:
40A
Coil Voltage:
12 VDC
Coil Current:
141.17 mA
Coil Resistance:
85 Ohm
Contact Material:
Silver Tin Oxide
Must Operate Voltage:
7.8 VDC
Must Release Voltage:
1.2 VDC
Operate Time:
7 ms
Seal:
Sealed
Mounting:
Bracket Mount
Termination Style:
0.25 Quick Connect
Dimension:
35.5 x 46.5 x 67.3 mm
Operating Temperature:
-55 to 110 °C
Packaging:
N/A
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is AZ973-1A-12DC4 discontinued?

Yes, AZ973-1A-12DC4 from American Zettler is discontinued. Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

Is AZ973-1A-12DC4 RoHS compliant?

Yes, AZ973-1A-12DC4 is RoHS compliant.

What is the lead time for AZ973-1A-12DC4?

The standard lead time for AZ973-1A-12DC4 is approximately 5 days. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock

IN STOCK: 4

Can Ship immediately

Price (USD)

Qty
Unit Price
1
$1.55
25
$1.52
50
$1.49
100
$1.46
500
$1.43
1,000 +
$1.40
Log in for special pricing Click for Quote Price Match Request
