AZ970-1C-12D by american zettler
Image is representational - see manufacturer specifications
American Zettler Authorized Distributor

AZ970-1C-12D

40AMP Automotive Relay 12VDC coil SPDT

View Datasheet
RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

40AMP Automotive Relay 12VDC coil SPDT

Search Keywords: AZ9701C12D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ970-1C-12D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Tray
Contact Form:
SPDT (1 Form C)
Relay Construction:
Non-Latching
Max Contact Current:
30A
Coil Voltage:
12 VDC
Coil Current:
133.33 mA
Coil Resistance:
90 Ohm
Contact Material:
Silver Tin Oxide
Must Operate Voltage:
6.8 VDC
Must Release Voltage:
0.72 VDC
Operate Time:
5 ms
Seal:
Unsealed
Mounting:
Through Hole
Termination Style:
PC Pin
Dimension:
18.8 x 23 x 18 mm
Operating Temperature:
-40 to 125 °C
Packaging:
N/A

FREQUENTLY ASKED QUESTIONS

Is AZ970-1C-12D RoHS compliant?

Yes, AZ970-1C-12D is RoHS compliant.

What is the lead time for AZ970-1C-12D?

The standard lead time for AZ970-1C-12D is approximately 9 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 295

Can Ship immediately

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 250

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
25
$1.90
50
$1.49
100
$1.47
250
$1.43
500
$1.40
750
$1.39
1,000 +
$1.38
Supplier's Standard Package
