AZ9481-1CE-5DE

16AMP Low Profile Power Relay 5VDC coil SPDT ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

AZ9481-1CE-5DE is a 16 amp low-profile power relay featuring SPDT (1 Form C) contact configuration with silver tin oxide (AgSnO2) contacts. The relay operates at a nominal coil voltage of 5 VDC with a must-operate voltage of 4 VDC and maximum continuous voltage of 6.5 VDC, with a coil resistance of 63 ohms. It delivers high power switching capability of up to 4000 VA with a maximum switched power of 300/180 W (N.O./N.C.) and maximum switched current of 10/6 A (N.O./N.C.) at 250 VAC or 30 VDC. The relay features high sensitivity with 128 mW pickup power, operates in a low-profile form factor (less than 0.5" height), and meets UL Class F (155°C) thermal rating with UL file E43203 and TÜV certification. With mechanical life expectancy of 1×107 operations and electrical life of 1×105 cycles at 10 A and 250 VAC, this relay is ideal for industrial control, power switching, and automation applications requiring reliable, compact switching solutions.

Search Keywords: AZ94811CE5DE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ9481-1CE-5DE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
63 Ohm
