AZ826-2C-12DME by american zettler
Image is representational - see manufacturer specifications
American Zettler Authorized Distributor

AZ826-2C-12DME

Sub-Mini Ultra-Sensitive DIP Relay 12VDC coil DPDT ...

View Datasheet Ask the Datasheet
RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The AMERICAN ZETTLER AZ826-2C-12DME is a high-quality Sub-Mini Ultra-Sensitive DIP Relay with a 12VDC coil. This relay is designed to provide reliable and efficient switching performance in a compact package. With a DPDT (Double Pole Double Throw) configuration, it offers versatile and flexible control options. Whether used in industrial automation, telecommunications, or other applications, this relay is known for its ultra-sensitive sensitivity, reliable operation, and long lifespan. Invest in the AMERICAN ZETTLER AZ826-2C-12DME for superior performance and peace of mind.

Search Keywords: AZ8262C12DME

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ826-2C-12DME
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
20.2 x 9.9 x 12 mm
Termination Style:
PC Pin
Coil Current:
30 mA
Contact Form:
2 Form C

FREQUENTLY ASKED QUESTIONS

What replaces AZ826-2C-12DME?

The recommended replacement for AZ826-2C-12DME is AZ830-2C-12DE from American Zettler, available from Master Electronics.

Is AZ826-2C-12DME RoHS compliant?

Yes, AZ826-2C-12DME is RoHS compliant.

What is the lead time for AZ826-2C-12DME?

The standard lead time for AZ826-2C-12DME is approximately 9 days. In-stock quantities ship from Master Electronics.

IN STOCK: 70

Can Ship immediately

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 250

Factory Lead-Time 9 Weeks
