AZ8-1CH-6DE by american zettler
Image is representational - see manufacturer specifications
American Zettler Authorized Distributor

AZ8-1CH-6DE

Mini PC Board Relay 6VDC coil SPDT ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The AMERICAN ZETTLER part AZ8-1CH-6DE is a compact and versatile mini PC board relay designed for reliable performance in various applications. It features a 6VDC coil and a single-pole double-throw (SPDT) configuration, allowing for flexible switching capabilities. This relay is ideal for compact electronic devices and can handle different voltage levels with ease. Trustworthy and durable, it is a valuable component that ensures reliable operation in your electronic projects.

Search Keywords: AZ81CH6DE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ8-1CH-6DE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Relay Construction:
Non-Latching10725
AC Coil Voltage:
N/A
DC Coil Voltage:
6 V
Contact Arrangement:
SPDT10703
Mounting:
Through Hole10716
Termination Style:
PC Pin10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-55 to 90 °C
Coil Resistance:
80 Ohm

FREQUENTLY ASKED QUESTIONS

Is AZ8-1CH-6DE RoHS compliant?

Yes, AZ8-1CH-6DE is RoHS compliant.

What is the lead time for AZ8-1CH-6DE?

The standard lead time for AZ8-1CH-6DE is approximately 20 days. In-stock quantities ship from Master Electronics.

IN STOCK: 0

On Order: 590   can ship 12/2/26

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 250

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
25
$3.04
50
$3.03
100
$3.02
250
$3.01
500
$1.86
750
$1.47
1,000 +
$1.44
