AZ2160-1C-15DEF

Name: AZ2160-1C-15DEF American Zettler Power Relays 20 Amps to 999 Amps
Brand: American Zettler
SKU: 10610721
Availability: InStock

40A Mini Power Relay 15VDC coil SPDT ...

View Datasheet

RoHS Compliant

Tray Packaging

Certificate of Compliance

DESCRIPTION

AZ2160-1C-15DEF is a miniature power relay featuring a single Form C (SPDT) contact arrangement with 40 A switching capability and a 15 VDC nominal coil voltage. The relay offers both PC and quick-connect terminal options, with AgSnO2 (silver tin oxide) contact material and a contact resistance of =20 mO. It delivers a mechanical life expectancy of 10 million operations and an electrical life of 100,000 cycles at 125 VAC with 30 A Form A contacts. The relay operates over a temperature range of -55°C to 105°C (Class F coil), features a dielectric strength of 2500 VRMS (coil to load contacts), and meets UL 508 and UL 873 spacing requirements. This relay is ideal for industrial control applications, HVAC systems, and refrigeration equipment where reliable switching and compact form factor are essential.

Product Highlights:

Potential Applications:

Search Keywords: AZ21601C15DEF

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

American Zettler

Part No:

AZ2160-1C-15DEF

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536410050

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
