SSSF011700 by alps electric
Image is representational - see manufacturer specifications
Alps Electric Authorized Distributor

SSSF011700

Switch Slide SP Top Slide 0.1A 30VDC 10000Cycles PC Pins Thru-Hole Bulk ...

View Datasheet Ask the Datasheet
RoHS Compliant
BULK Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

SSSF011700 is a large-size general-purpose tactile push switch designed for diverse industrial and consumer applications. It features an 8.5 mm height with 2 mm key travel, vertical actuator orientation, and a 6 mm actuator length in a 1-pole 2-position configuration. The switch is rated for a maximum of 0.1 A at 30 V DC and a minimum of 10 µA at 1 V DC, with initial contact resistance of 25 mO maximum and 65 mO maximum after lifetime testing. It delivers an operating force of 2.5 N with detent and maintains 10,000 cycles of operating life both with and without load (0.1 A 30 V DC). The switch employs snap-in mounting with 1.6 mm PCB thickness and is well-suited for control panels, consumer electronics, and industrial equipment requiring reliable tactile feedback and long-term durability.

Search Keywords: SSSF011700

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Alps Electric
Part No:
SSSF011700
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
4000
Package Type:
BULK
Mounting:
PCB Through Hole
Body Orientation:
Straight
Actuator Style:
Top Slide
Pole Throw Configuration:
SPDT
Switch Configuration:
N/A
Contact Rating @ Voltage:
0.1@30VDC A
Contact Plating:
N/A
Operating Temperature:
-40 to 85 °C
Termination Style:
PC Pins
Dimension:
14.5 x 7 x 14.5 mm

FREQUENTLY ASKED QUESTIONS

Is SSSF011700 RoHS compliant?

Yes, SSSF011700 is RoHS compliant.

What is the lead time for SSSF011700?

The standard lead time for SSSF011700 is approximately 18 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 1

Can Ship immediately

Buy all 1 in-stock or the regular minimum order quantity of 50

On Order: 4,000   can ship 1/25/27

Stock lot only: 1

Minimum Order Quantity: 50

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
1
$1.0527
50
$0.9570
500
$0.6700
1,000
$0.6040
4,000
$0.5630
8,000
$0.5610
12,000
$0.5600
16,000
$0.5580
28,000 +
$0.5570
