F2211IN-WH105

Name: F2211IN-WH105 Alpha Wire Heat Shrink
Brand: Alpha Wire
SKU: 39136967
Availability: InStock

FIT-221 1" - White - 5x4ft/Pkg ...

View Datasheet Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

FIT2211IN-WHITE-5X4 is a white heat shrinkable tubing made from cross-linked polyolefin material, designed for wire and cable insulation and protection. It features a minimum supplied inner diameter of 1.000 inch that shrinks to a maximum recovered inner diameter of 0.500 inch with an approximate 2:1 shrink ratio, and a nominal recovered wall thickness of 0.035 inch. The tubing operates over a temperature range of -55 to 135°C, with a minimum shrink temperature of 90°C and full recovery at 121°C. It is UL 224 and CSA 198 rated for 600V and meets AMS-DTL-23053/5 Class 1 specifications. This tubing is ideal for applications requiring electrical insulation, mechanical protection, and environmental sealing in industrial, aerospace, and general electronics environments.

Product Highlights:

Potential Applications:

Search Keywords: F2211INWH105

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

F2211IN-WH105

Alias/AKA:

F2211IN-WHITE-20, FIT2211IN-WHITE-5X4

Unit of Measure:

Per Foot

RoHS:

Yes

HTS:

3917320050

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
