9058X-BK002

Name: 9058X-BK002 Alpha Wire Cable Coaxial
Brand: Alpha Wire
SKU: 10133135
Availability: BackOrder

The 9058X-BK002 is an RG-58/U type coaxial cable featuring a 20 AWG solid bare copper conductor and a tinned copper braid shield. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 9058X-BK002 is an RG-58/U type coaxial cable designed for signal transmission. It is constructed with a 20 AWG solid bare copper conductor, polyethylene insulation, and a tinned copper braid shield that provides a minimum of 95% coverage for excellent noise protection. The cable has a characteristic impedance of 51.5 Î©, a nominal ground capacitance of 28.5 pF/ft, and a velocity of propagation of 66%. Encased in a black Type I PVC jacket, it has an overall nominal diameter of 0.195 inches and an operating temperature range of -20Â°C to 60Â°C. This cable is compliant with UL CMX, AWM Style 1354, and military specification JAN-C-17A, making it suitable for various communication and instrumentation applications.

Product Highlights:

Potential Applications:

Search Keywords: 9058XBK002

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

9058X-BK002

Alias/AKA:

9058X-BLACK-500

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544200000

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
