Image is representational - see mfr. specs

79047-SLATE-100

Name: 79047-SLATE-100
Brand: Alpha Wire
SKU: 45664693
Price: 733.41 USD
Availability: InStock

Alpha Wire

Multi-Conductor Cable 6 Conductors 22AWG 6.09mm 600VAC - Slate - 30.48m (100ft)/Spool ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 79047-SL005 is a six-conductor control cable featuring 22 AWG tinned copper conductors with modified polyphenylene ether (MPPE) insulation and jacket. Each conductor has an insulation wall thickness of 0.0095 inches nominal, with an overall cable diameter of 0.228 ± 0.012 inches and a jacket wall thickness of 0.035 inches nominal. The cable is constructed with six components cabled at 6.9 twists per foot minimum, wrapped with nonwoven polyester tape at 25% overlap, and features a slate-colored jacket with standard color coding (black, red, white, green, orange, blue). It is rated for 600V RMS at 105°C (AWM/STYLE 21819) or 300V RMS at 80°C (AWM/STYLE 21492), with VW-1 flame rating and CSA C(RU) AWM I/II A/B FT1 certification. This cable is ideal for industrial control, instrumentation, and equipment wiring applications requiring halogen-free, RoHS-compliant construction with reliable multi-conductor performance.

Product Highlights:

Potential Applications:

Search Keywords: 79047SLATE100

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

79047-SLATE-100

Alias/AKA:

79047-SL005

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544.42.900

COO:

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
