Image is representational - see mfr. specs

784133-BK005

Alpha Wire

A 4 AWG single-conductor hook-up wire featuring a stranded tinned copper conductor and PVC insulation. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 784133-BK005 is a single-conductor hook-up wire designed for the internal wiring of electrical and electronic equipment. It is constructed with a 4 AWG tinned copper conductor with 133(7x19)/25 stranding and a nominal diameter of 0.269 inches. The conductor is insulated with a 0.063-inch wall of PVC, resulting in an overall nominal diameter of 0.395 inches. This wire is rated for 600 VRMS and has a wide operating temperature range of -40Â°C to 105Â°C. Compliant with multiple UL (MTW, THW, AWM 1283/1232) and CSA (TEW-105) standards, it is a reliable choice for various general-purpose applications.

Product Highlights:

Potential Applications:

Search Keywords: 784133BK005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

784133-BK005

Alias/AKA:

784133-BLACK-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
