541419-GR005

Name: 541419-GR005 Alpha Wire Cable Single Conductor
Brand: Alpha Wire
SKU: 39131408
Availability: InStock

A 14 AWG single-conductor hook-up wire rated for 600V and suitable for UL Type THHN and THWN applications. ...

View Datasheet Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 541419-GR005 is a single-conductor hook-up wire designed for general-purpose internal wiring. It is constructed with a 14 AWG stranded (19/.0147) bare copper conductor for excellent conductivity and flexibility. The insulation consists of a 0.016" PVC wall with a protective 0.005" nylon jacket, resulting in a nominal outer diameter of 0.116 inches. This wire is UL listed as Type THHN for use up to 90Â°C and Type THWN for wet or dry conditions up to 75Â°C, both with a voltage rating of 600 VRMS. Its robust design and wide operating temperature range make it ideal for wiring control panels, machine tools, and other electrical equipment.

Product Highlights:

Potential Applications:

Search Keywords: 541419GR005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

541419-GR005

Alias/AKA:

541419-GREEN-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
