3070-RD005

Name: 3070-RD005 Alpha Wire Cable Single Conductor
Brand: Alpha Wire
SKU: 10122454
Availability: InStock

Hook-up Wire 24AWG 2.24mm Tinned Copper - Red - 600V Spool - 30.48m (100ft)/Spool ...

View Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 3070-RD005 is a single-conductor hookup wire featuring 24 AWG tinned copper conductor with 0.032" nominal PVC insulation wall thickness, designed for general-purpose electrical connections. It is rated for 600V RMS and operates reliably across a temperature range of -40°C to 105°C, meeting AWM Style 1015/1230 and VW-1 flame rating standards. The wire exhibits a nominal inductance of 0.09 µH/ft and a conductor DC resistance of 25 O/1000ft at 20°C, with a maximum pull tension of 3.5 lbs and a minimum bend radius of 5 times the cable diameter. This hookup wire is ideal for internal wiring in electronic equipment, control circuits, and general-purpose applications where compact gauge and reliable insulation are required.

Product Highlights:

Potential Applications:

Search Keywords: 3070RD005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

3070-RD005

Alias/AKA:

3070-RED-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
