3057-RD001

Name: 3057-RD001 Alpha Wire Cable Single Conductor
Brand: Alpha Wire
SKU: 10122337
Availability: InStock

Hook-up Wire 16AWG 2.41mm Tinned Copper - Red - 300VAC - 304.8m (1000ft)/Spool ...

View Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 3057-RD001 is a single-conductor hookup wire featuring 16 AWG (26/30 stranded) tinned copper conductor with 0.016" nominal PVC insulation wall thickness. It is rated for 300V RMS and operates reliably across a temperature range of -40°C to +105°C, meeting UL AWM styles 1569 and 1007 standards with VW-1 flame rating. The wire exhibits a nominal conductor DC resistance of 4.4 O/1000ft at 20°C and an inductance of 0.04 µH/ft, with a maximum pull tension of 20.4 lbs and a minimum bend radius of 10 times the cable diameter. This hookup wire is ideal for general-purpose electrical interconnections, control circuits, and applications requiring reliable insulation and flame resistance in industrial and commercial equipment.

Product Highlights:

Potential Applications:

Search Keywords: 3057RD001

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

3057-RD001

Alias/AKA:

3057-RED-1000

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
