3053-BR001

Name: 3053-BR001 Alpha Wire Cable Single Conductor
Brand: Alpha Wire
SKU: 10122056
Availability: InStock

Hook-up Wire 20AWG 304.8m 1.8mm Tinned Copper- Brown - 300VAC - 304.8m (1000ft)/Spool ...

View Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 3053-BR001 is a single-conductor hookup wire featuring 20 AWG (10/30) tinned copper conductor with nominal 0.016" wall PVC insulation. It is rated for 300 VRMS and complies with UL AWM styles 1007 (80°C) and 1569 (105°C), as well as CSA TR-64 (90°C) and FT1 standards, with VW-1 flame rating per IEC 60332-1. The wire operates reliably across a temperature range of -40°C to +105°C and features a maximum pull tension of 7.9 lbs with a minimum bend radius of 10 times the cable diameter. This hookup wire is ideal for general-purpose electrical interconnections, control circuits, and instrumentation applications where compact gauge and reliable insulation are required, and it is fully RoHS 2/3 compliant for modern electronic equipment.

Product Highlights:

Potential Applications:

Search Keywords: 3053BR001

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

3053-BR001

Alias/AKA:

3053-BROWN-1000

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
