3048-YL005

Name: 3048-YL005 Alpha Wire Cable Single Conductor
Brand: Alpha Wire
SKU: 10121733
Availability: BackOrder

Hook-up Wire 28AWG 1.19mm Tinned Copper - Yellow - 300VAC - 30.48m (100ft)/Spool ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 3048-YL005 is a single-conductor hookup wire designed for general-purpose electrical applications requiring reliable insulation and conductivity. It features a 28 AWG tinned copper conductor with a nominal 0.016" PVC insulation wall, providing an overall diameter of 0.047 ± 0.002 inches. The wire is rated for 300 V RMS and operates across a temperature range of -40°C to 105°C, meeting UL AWM/STYLE 1007 (80°C) and STYLE 1569 (105°C) standards, as well as CSA TR-64 and FT1 specifications. With a maximum pull tension of 1.37 lbs and a bend radius of 10× cable diameter, this wire is suitable for internal wiring in electronic equipment, control circuits, and general hookup applications where space and flexibility are important considerations.

Product Highlights:

Potential Applications:

Search Keywords: 3048YL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

3048-YL005

Alias/AKA:

3048-YELLOW-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
