Image is representational - see mfr. specs

2844/19-WH001

A 24 AWG single-conductor hook-up wire featuring a stranded silver-plated copper conductor and high-temperature PTFE insulation. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 2844/19-WH001 is a high-performance hook-up wire compliant with MIL-W-16878/6 (Type ET) specifications. It is constructed with a 24 AWG (19/36) stranded silver-plated copper conductor and a 0.006-inch nominal wall of white PTFE insulation. This construction provides a wide operating temperature range from -60Â°C to 200Â°C and a voltage rating of 250 VRMS. Its durability and stable electrical properties make it suitable for internal wiring in demanding electronic, military, and aerospace applications.

Product Highlights:

Potential Applications:

Search Keywords: 284419WH001

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

2844/19-WH001

Alias/AKA:

2844/19-WHITE-1000

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
