Image is representational - see mfr. specs

1181C-SL005

Alpha Wire

Multi-Conductor Cable Polyvinyl Chloride 12 Conductors 22AWG 7.28mm 300VAC - Slate - 30.48m (100ft)/Spool ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 1181C-SLATE-100 is a multi-conductor cable designed for communication and control applications. It consists of 12 color-coded, 22 AWG stranded (7/30) tinned copper conductors, each with a 0.010-inch PVC insulation wall. The cabled core has a minimum twist rate of 4.0 twists per foot and is protected by a durable, slate-colored PVC jacket with a nominal thickness of 0.032 inches, resulting in an overall nominal diameter of 0.272 inches. This cable has a voltage rating of 300 VRMS and an operating temperature range of -20Â°C to 80Â°C. Its UL Type CM and CSA Type CMG ratings make it suitable for general-purpose instrumentation and control systems.

Product Highlights:

Potential Applications:

Search Keywords: 1181CSL005

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

1181C-SL005

Alias/AKA:

1181C-SLATE-100

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
