2SH-C-05-TS by adam tech
Image is representational - see mfr. specs

2SH-C-05-TS

Adam Tech

Connector Header Vertical 5Position 2mm - Bag ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 2SH-C-05-TS is a straight PCB-mounted connector header designed for reliable electrical interconnection in low-voltage applications. It features a Nylon 66 insulator body rated UL 94V-0 with white coloring, brass contacts plated with tin over copper underplate, and supports 2 to 15 positions with 0.079 inch (2.00 mm) pitch spacing. The connector is rated for a maximum operating voltage of 100 VAC and current rating of 2 Amps, with contact resistance of 10 milliohms maximum and insulation resistance of 1,000 megohms minimum at 500 VDC. Operating temperature range spans -25°C to +85°C, and the product is RoHS compliant and lead-free. This connector is ideal for PCB-to-wire or PCB-to-PCB connections in consumer electronics, industrial control systems, and general-purpose low-voltage applications requiring cost-effective, reliable interconnection.

Search Keywords: 2SHC05TS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Adam Tech
Part No:
2SH-C-05-TS
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
BAG

IN STOCK: 10,000

Can Ship immediately

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
1,000
$0.0397
3,000
$0.0390
8,000
$0.0384
25,000
$0.0377
50,000
$0.0372
100,000
$0.0331
150,000
$0.0329
250,000 +
$0.0305
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
