325-103 by abbatron / hh smith
Image is representational - see manufacturer specifications
Abbatron / HH Smith Authorized Distributor

325-103

Printed Circuit Test Jacks - 1/16" Board Thickness - 0.130" Length - Black.

View Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 325-103 are printed circuit test jacks with double entry design, probe inserts at either end of jack. Accepts probes no larger than 0.084", contacts down to 0.074". Closed bottom construction keeps jack from fouling with solder or flux. Locking ears h

Search Keywords: 325103

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Abbatron / HH Smith
Part No:
325-103
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536908085
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
Test Jack
Gender:
F
Body Orientation:
Right Angle
Mounting:
Through Hole
Number of Contacts:
2
Wire Size:
N/A
Maximum Current Rating:
5 A
Operating Temperature:
N/A
Dimension:
12.19 x 3.96 x 5.58 mm

FREQUENTLY ASKED QUESTIONS

Is 325-103 RoHS compliant?

Yes, 325-103 is RoHS compliant.

What is the lead time for 325-103?

The standard lead time for 325-103 is approximately 9 days. In-stock quantities ship from Master Electronics.

IN STOCK: 200

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
100
$2.805
300
$2.717
500
$2.605
1,000
$2.579
2,500
$2.572
5,000
$2.368
7,500
$2.362
10,000 +
$2.063
Supplier's Standard Package
