2609

The 2609 is a ceramic standoff insulator made from L5 Steatite with a glazed finish, designed for electrical and mechanical mounting. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 2609 is a ceramic standoff insulator, designated as MIL Type NL523W02-008. It is manufactured from L5 Steatite material per MIL-I-10 and features a glazed finish for added protection and insulation. This standoff has a body diameter ('B') of 1/2 inch, a terminal height ('C') of 3/16 inch, and is tapped with an 8-32 thread. Conforming to the MIL-I-23264 manufacturing standard, the 2609 provides reliable mechanical support and electrical isolation in various electronic assemblies.

Search Keywords: 2609

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Abbatron / HH Smith
Part No:
2609
Unit of Measure:
Per Each
RoHS:
Yes
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
5
Body Length:
25.4 mm
Outer Diameter:
12.7 mm
Type:
Round
Material:
Ceramic
Thread Size:
8-32

FREQUENTLY ASKED QUESTIONS

Is 2609 RoHS compliant?

Yes, 2609 is RoHS compliant.

What is the lead time for 2609?

The standard lead time for 2609 is approximately 9 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 500

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 38

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$15.20
10
$12.74
25
$11.78
38
$11.75
75
$11.40
113
$10.93
150 +
$10.80
